Pneumatic Trim Shears
EC-7 EC-8 EC-9 EC-10

EC Eng. & Mfg. has four basic trim shear models: EC-7, EC-8, EC-9, and EC-10. All trim shears are designed to cut steel, stainless steel, titanium, inconel, and similar metals. Individual capacity depends on the size of the tool (see below).

In order to accommodate as many production requirements as possible, all our tools are equipped with reversible pneumatic motors. The advantages of having a reversible motor are:

  1. If the tool for some reason would stall or jam, the operator flips a lever or turns a knob, depending on which tool he is using, and the tool will reverse rotation and work itself loose.
  2. The tool can be used to operate away from, as well as towards, the operator.
  3. Allows for “In and Out” shearing.

The ultimate in shearing may be expected from these portable trim shears.

EC-7 LR *

  • Mild Steel Capacity – 13 Gauge
  • Feed – Approximately 8 feet/minute
  • Throat Capacity – 1 1/4 inches
  • Weight – 4 1/2 pounds
  • Length – 10 1/4 inches
  • Height – 3 13/16 inches
  • Width – 3 1/4 inches
  • Minimum Hose Size – 5/16 inch

EC-7 PR *

  • Mild Steel Capacity – 13 Gauge
  • Feed – Approximately 8 feet/minute
  • Throat Capacity – 1 1/4 inches
  • Weight – 5 pounds
  • Length – 8 1/4 inches
  • Height – 3 13/16 inches
  • Width – 3 1/4 inches
  • Minimum Hose Size – 5/16 inch

EC-8 LR *

  • Mild Steel Capacity – 14 Gauge
  • Feed – Approximately 8 feet/minute
  • Throat Capacity – 2 1/4 inches
  • Weight – 5 1/2 pounds
  • Length – 10 1/4 inches
  • Height – 3 13/16 inches
  • Width – 4 1/4 inches
  • Minimum Hose Size – 5/16 inch

EC-8 PR *

  • Mild Steel Capacity – 14 Gauge
  • Feed – Approximately 8 feet/minute
  • Throat Capacity – 2 1/4 inches
  • Weight – 5 1/2 pounds
  • Length – 8 1/4 inches
  • Height – 3 13/16 inches
  • Width – 4 1/4 inches
  • Minimum Hose Size – 5/16 inch

EC-9 PR *

  • Mild Steel Capacity – 10 Gauge
  • Feed – Approximately 3 1/2 feet/minute
  • Throat Capacity – 2 1/2 inches
  • Weight – 12 1/2 pounds
  • Length – 11 5/8 inches
  • Height – 5 5/8 inches
  • Width – 5 inches
  • Minimum Hose Size – 3/8 inch

EC-10 PR *

  • Mild Steel Capacity – Up to 0.080 Inconel
  • Feed – Approximately 3 1/2 feet/minute
  • Throat Capacity – 2 inches
  • Weight – 19 pounds
  • Length – 12 1/8 inches
  • Height – 7 3/8 inches
  • Width – 5 inches
  • Minimum Hose Size – 3/8 inch

* L = Straight Motor     P = Pistol Grip Motor    R = Reversible Motor
